Our Capabilities
Five integrated processes under one roof to take your project from blueprint to reality.
Laser Cutting
Precision at industrial scale
AMADA REGIUS-3015AJe 6 kW fibre laser cutting for steel, stainless steel and aluminium. Useful format of 3,070 × 1,550 mm and up to 25 mm thick depending on material, with linear motors on all 3 axes and ±0.01 mm repeatability.
- AMADA REGIUS-3015AJe — 6 kW
- Format 3,070 × 1,550 mm
- Up to 25 mm in steel, stainless and aluminium
- Linear motors · ±0.01 mm
- Guaranteed repeatability in series production
Technical sheet AMADA REGIUS-3015AJe · 6 kW
Potencia y tipo
- Tecnología
- Corte por láser de fibra
- Potencia
- 6.000 W (6 kW)
Capacidad de corte
- Acero al carbono
- Hasta 25 mm
- Acero inoxidable
- Hasta 25 mm
- Aluminio
- Hasta 25 mm
- Latón
- Hasta 15 mm
- Cobre
- Hasta 12 mm
Área de trabajo y cargas
- Área útil (X × Y)
- 3.070 × 1.550 mm
- Carrera eje Z
- 100 mm
- Peso máximo de material
- 920 kg
Rendimiento y precisión
- Velocidad combinada X/Y
- 340 m/min
- Repetitividad
- ±0,01 mm
- Accionamiento
- Motores lineales en 3 ejes
Control y automatización
- CNC
- AMNC 4ie · pantalla táctil HD 21,5"
- Centrado automático de boquilla
- i-Nozzle Checker
- Monitorización de proceso
- i-Process Monitoring
- Optimización de rayo
- Control variable ENSIS
- Recuperación automática tras colisión
- Sí
Dimensiones de la máquina
- Longitud total
- 10.346 mm
- Anchura total
- 2.990 mm
- Altura total
- 2.450 mm
- Peso de máquina
- 11.900 kg
CNC Bending
Complex geometries with full repeatability
Two state-of-the-art AMADA CNC press brakes, with the HFE3i-1704 (170 t and 4.2 m) as our flagship. Hydraulic sheet followers, AMNC 3i CNC control, 5-axis back gauge and patented deflection compensation to guarantee part-to-part repeatability in short and long runs.
- 2 AMADA CNC press brakes
- Up to 170 t and 4.2 m length
- Hydraulic sheet followers
- 5-axis back gauge · AMNC 3i
- Patented deflection compensation
Technical sheet AMADA HFE3i-1704 · 170 Tn · 4,2 m
Capacidades principales
- Fuerza de plegado
- 1.700 kN (170 Tn)
- Longitud útil de plegado
- 4.230 mm
- Distancia entre montantes
- 3.760 mm
- Profundidad de garganta
- 420 mm
- Carrera
- 200 mm
- Apertura (luz de trabajo)
- 470 mm
- Altura de trabajo
- 960 mm
Velocidades
- Aproximación
- 100 mm/s
- Plegado
- 10 mm/s
- Retorno
- 100 mm/s
Control y automatización
- CNC
- AMNC 3i · pantalla táctil 18,5"
- Accionamiento
- Sistema hidráulico ECO
- Compensación de deformación
- Patentada
- Medición de ángulo
- DIGIPRO · BI-S · BI-M (opcional)
- Back gauge
- 5 ejes + FAST (opcional)
- Programación offline
- VPSS 3i Bend
- Conectividad
- Industry 4.0
Dimensiones de la máquina
- Longitud total
- 5.710 mm
- Anchura total
- 2.700 mm
- Altura total
- 2.890 mm
- Peso
- 13.900 kg
Technical sheet AMADA HRB-1003 · 100 Tn · 3 m
Capacidades principales
- Fuerza de plegado
- 1.000 kN (100 Tn)
- Longitud útil de plegado
- 3.000 mm
- Apertura (luz de trabajo)
- 520 mm
- Carrera
- 250 mm
Velocidades
- Aproximación
- 200 mm/s
- Plegado
- 15 mm/s
- Retorno
- 150 mm/s
Control y automatización
- CNC
- AMNC 3i · pantalla táctil 18,5"
- Accionamiento
- Hidráulico con inverter (ahorro energético)
- Compensación de deformación
- Auto-crowning
- Medición de ángulo
- Bi-S mecánico automático
- Back gauge
- Delta X · Z independiente · R (configurable)
- Seguridad en topes traseros
- FAST (opcional)
Dimensiones de la máquina
- Longitud total
- 4.880 mm
- Anchura total
- 3.100 mm
- Altura total
- 2.680 mm
EN 15085 Certified Welding
Structural joints of maximum reliability
EN 15085 certified welding with our own welding engineer and individually qualified welders. MIG/MAG, TIG and spot welding on dynamic, high-responsibility products.
- EN 15085 — Railway welding
- In-house welding engineer
- Individually qualified welders
- MIG/MAG · TIG · Spot welding
- Dynamic and structural product
Assembly and Testing
From component to finished assembly
Complete assembly of metal sub-assemblies and assemblies, integrating mechanical, electrical and pneumatic components. We perform tightness tests and dimensional control before delivering the product ready to install.
- Complete assemblies and sub-assemblies
- Multidisciplinary integration
- Tightness testing
- Dimensional control
- Ready to install
Finishing and Coordination
Surface treatments under our control
We coordinate finishings and surface treatments with subcontractors approved by the end clients themselves. Same traceability, no break in the standard: paints, passivations, electroplating coatings and technical adhesives.
- Subcontractors approved by the end client
- Paint and anti-corrosion treatments
- Passivations and electroplating coatings
- Certified structural adhesives
- Full process traceability
End-to-end Process
Cutting, bending, welding and assembly under our direct control. Surface treatments are coordinated with subcontractors approved by our own end clients, keeping the same traceability.
